Union 2234E - British Standard 5 Lever Sashlocks - Blister

Backset: 45mm, 57.5mm

Finish: Polished Brass

Lockcase Size: 67mm (2.5"), 79.5mm (3")

Lockcase Type: Sashlock

Ref	Name
UNDY2234EPL2.5	Union 2234E - BS 5 Lever Mortice Sash Lock (2.5")
UNDY2234EPL3	Union 2234E - BS 5 Lever Mortice Sash Lock (3")

Description

Application

For timber doors hinged on left or right and requiring key & lever handle operation
To suit doors up to 54mm thick

Specification

Deadbolt locked or unlocked by key from either side
Latch bolt withdrawn by lever handle from either side
Extended 20mm deadbolt for secure positive deadlocking and additional resistance against attack
2234E may be keyed alike with 2134E
Pierced to accept bolt through furniture
NB: Not suitable for master keying
Reversible latch bolt from outside of case
Anti-pick and anti-saw security features
Available with square forend and striking plate
Case Size: 67mm (2.5") or 79.5mm (3")
Backset: 45mm or 57.5mm
Case: Steel, red powder coat
Forend: Stainless steel or brass
Striking Plate: Security box type, finished to match forend
Deadbolt: Brass, with hardened steel rollers
Latch Bolt: Brass, reversible
Follower: Brass, 8mm square
Rebate Kit: 2964 (13mm, 19mm or 25mm)
Keying Groups: Supplied to pass, differ and keyed alike. Supplied with 3 steel nickel plated keys
Key Blank Number: KB430

Standards
